Tool Dynamometer - Milling Tool Dynamometer

Unitech offers tool dynamometers to measure cutting forces on various machines like lathe, drill, milling machines. All three direction forces are measured simultaneously and displayed. Tool dynamometers are useful to study, analyse the optimum feed, speed and depth of cut on different materials. The dynamometers are also available in various capacities as per customer requirement.




SPECIFICATION
Model
Capacity
Mounting Type

Sensor Type
Job Mountry
Display
Resolution
Recorder O/P

Zero Balancing
Power
Enclosure
Accessories

Optional (Extra Cost)		 :  UIM 14
:  500Kg in X,Y & Z direction.
:  350(L) x 350(W) x 100(H)mm.
:  to mount on the machine bed.
:  Straingauge based 350 Ω bridge.
:  Mounting holes M10 provided to fix machine vise.
:  3 independent for x,y & z force. LED display 3½ digit.
:  1Kg for all the 3 Components.
:  Analog output for connect any recorder or data logger
   provided.
:  Corse and fine potentiometer on front panel.
:  230V 50 Hz
:  Powder coated metal box.400(L)x300(W)x100H
:  Self centering vise 4”-1No.
:  Necessary cables provided.
:  RS232 Interface to connect computer for datalogging with
   LCD display.
