Module
comprise of a small FHP DC motor with a driver card.6
bit DAC card is provided to convert digital signal
to analog signal. The analog signal is used to control
the drive card which in turn controls the dc motor.
SPECIFICATION
Inputs
Outputs
Logic level
Connection
Measurements
: 24V
AC for driver card,±15V DC for DAC card. : 2 push button for motor
ON/OFF, 2 toggle switch for
control selection. : 24V DC. : via 4mm patch card. : H-110×B-350×W-200.
